Home > Products > Bag Filter Equipment > Auto Snap Band Making Machine
Product Details
Product Name: Auto Snap Band Making Machine
Product No.: ABM-200-1

Characteristics
Airgrande offers auto snap band making machine from the one and only supplier that can make a machine of this kind - ZGTEK. Except ZGTEK, no one else can supply this machine. The machine is stable, fast, totally automatic, really a good way of automatizing your production.

Auto snap band making machine parameters(Model ABM-200-1):
  • Snap band diameter: 100-200mm(up to 300mm can be custom made)
  • Snap band width: 19mm,20mm,25mm,30mm,35mm,40mm, etc.
  • Rivets spec: 3mm, half hollow
  • Speed: 8s per piece
  • Voltage: 220V 50/60Hz, or customized
  • Power: 2.5KVA
  • Compressed air consumption: 300L/min
  • Air pressure: 0.6-0.8MPa
